8601

Programmable DC Electronic Loads

• Wide voltage and current range, 0 to 500 V, 0 to 240 A
• CC/CV/CR/CW operating modes
• Transient mode up to 25 kHz
• 16-bit resolution voltage and current measurement
• List mode function
• Adjustable slew rate in CC mode
• Short circuit test
• Built-in battery test function with voltage level, capacity level, and timer stop conditions
• CR-LED mode to simulate the loading behavior of typical LEDs
• Remote voltage sensing to compensate for the effect of voltage drop in wires
• Analog current control and monitoring
• Standard USB (USBTMC-compliant) and RS232 interfaces with SCPI protocol support
• GPIB optional on select models
• OVP/OCP/OPP/OTP and local/remote reverse voltage (LRV/RRV) protection
